| AC Power: | 100-130/200-260 V, 50/60 Hz, 6 W |
| Accuracy: | ±5% of full scale CW, ±8% PEP, VSWR: ±10% of reading, % Modulation: (CW power 1/3 or more of full scale) ±5% (0-90%), ±10% (90-100%) |
| Battery Life: | 8 hours (rechargeable) |
| Connector: | QC Type (Female N normally supplied) |
| Display: | 3 1/2 digit, 0.3" LED strobed |
| Finish: | Blue vinyl with silver anodized side panels |
| Frequency Range: | 450 kHz to 2.7 Ghz |
| Insertion VSWR: | with N connectors 1.05 max. to 1000 MHz |
| Meter Scales: | FWD and RFL 25, 50, 100 W |
| Modulation Frequency: | 25 to 10,000 Hz (Audio) |
| Nominal Size: | (includes connectors) 9 9/16" L x 5 7/32" W x 4 5/16" H (243 mm x 158 mm x 110 mm) |
| Power Rating: | 100 mW to 10 kW using Bird Plug-in Elements |
| Pulse Parameters: | (min.) Pulse width 0.8 μs (100-2700 MHz), 1.5 μs (26-99 MHz) and 15 μs (2-25 MHz), Repetition Rate 25 PPS, and Duty Factor 1 x 10^4 |
| Return Loss: | ±0.3 dB to corresponding SWR value |
| Sampling Rate: | 2 to 3 readings per second |
| Usable Over-range: | to 120% of scale (CW, PEP, SWR and Return Loss) |
| Weight: | 5 3/4 lbs. (2.6 kg) |
